| *No. |
*PART
NAME |
*MAT’L |
REMARKS |
|
|
|
**1
|
*BODY
|
*A351GR
CF8/CF8M
|
|
|
**2
|
*CAP
|
*A351GR
CF8/CF8M
|
|
|
**3
|
*BALL
|
*A351GR
CF8/CF8M
|
|
|
**4
|
*STEM
|
*A276
GR 304/316
|
|
|
**5
|
*SEAT
RING
|
*REINFORCED
PTFE
|
|
|
**6
|
*GASKET
|
*REINFORCED
PTFE
|
|
|
**7
|
*BACK
SEATRING
|
*REINFORCED
PTFE
|
|
|
**8
|
*STEM
PACKING
|
*REINFORCED
PTFE
|
|
|
**9
|
*WASHER
|
*A276
GR 304
|
|
|
*10
|
*LOCK
NET
|
*A276
GR 304
|
|
|
*11
|
*HANDLE
|
*A276
GR 304
|
|
|
|
| |
| DIMENSIONS |
(mm)
|
| |
| Vaive |
SIZE
|
8A
|
10A
|
15A
|
20A
|
25A
|
32A
|
40A
|
50A
|
65A
|
80A
|
|
10Kfg㎠
&
1501bf / in
|
L
|
48
|
48
|
59
|
67.5
|
83
|
91
|
100
|
115
|
130
|
155
|
|
H
|
30
|
37
|
41
|
45
|
55
|
60
|
69
|
75
|
100
|
107
|
|
W
|
70
|
70
|
81
|
100
|
107
|
107
|
134
|
150
|
180
|
180
|
|
|
| |
|
